FIMER PVX 241kWh Containerised Energy Storage System - PVX-241kWh
SKU Code:
FIM-20261022073546-726
Location:Italy
Prices list
1 - 2 pcsUSD 50085.39 /pc
Product Details
Product Details
Model NamePVX-241kWh
Nominal Voltage768 V (648–852 V range)
Rated Power/ Capacity241 kWh (314 Ah)
Product Measurements
Product Measurements
Height2100 mm
Width1150 mm
Depth1800 mm
Weight2800 kg
The FIMER PVX-241 is a 241kWh containerised energy storage system for commercial and industrial sites, built on LFP cells with hybrid cooling.
Nominal capacity is 314Ah at 768V rated voltage, with an operating window of 648–852V and maximum charge and discharge current of 183A. Maximum cycle rate 0.45 CP.
The system connects at 380/400/415V AC with 155.9A rated charge and discharge current at 400VAC, and includes Type II surge protection on the AC port. Supplied as a complete outdoor enclosure at 2.8 tonnes.
Total (Tax Excluded)USD 50085.39
Price (per piece):USD 50085.39
Available now:2 pcs
* Please choose address and incoterm for checkout
Lead Time1 Week(s)
